CT of the abdomen and pelvis
Author:
Mikael Häggström [notes 1]
Emergencies
Locations
Basic screening
Compare with any previous exam.
Example approach:
Liver, spleen, adrenals and kidneys
Scan through the entire volumes and look mainly for focal changes.
- The thickness of the adrenal glands is normally up to 1.0 cm.[1]
Further information:
- Look at the gallbladder and biliary tract for visible stones or dilatation.
- Also exclude hydronephrosis of the kidneys.
Free gas
Switch to a lung window (wide attenuation range), with main focus on the anterior wall, where gas most likely appears.
While in this window, also have a glance at the bases of the lungs for pleural fluid or obvious lung tumors.
Free fluid
Look mainly in the hepatorenal recess and inferiorly in the pelvis.
Lymph nodes
Look mainly around the aorta and iliac arteries.
Retrocrural space | 6 mm[2] |
Paracardiac | 8 mm[2] |
Gastrohepatic ligament | 8 mm[2] |
Upper paraaortic region | 9 mm[2] |
Portacaval space | 10 mm[2] |
Porta hepatis | 7 mm[2] |
Lower paraaortic region | 11 mm[2] |
Small intestine
On CT scans, a small intestinal diameter of over 2.5 cm is considered abnormally dilated.[3][4][5]
Large intestine
- Exclude dilatations.
- Check the intestinal wall for any thickening of over 5 mm.[7] Focal, irregular and asymmetrical gastrointestinal wall thickening suggests a malignancy.[7] Segmental or diffuse gastrointestinal wall thickening is most often due to ischemic, inflammatory or infectious disease.[7]
Aorta
- Exclude aneurysm, which is generally defined as over 3 cm.[8]
- Further information: CT of abdominal aneurysm
Urinary bladder
Quick look for obvious wall thickening.
Reproductive system
Males: Quick look at the prostate for obvious irregularities.
Females: Look mainly at the locations of the ovaries for any expansions.
Skeleton
Any signs of damage.
Other extra-peritoneal volumes
Quick overview to exclude mainly obvious soft tissue expansions such as hematomas (see CT of muscular hematoma).
Report
Example report in a normal abdomen:
No free gas or ascites
|
- See also: General notes on reporting
Special cases
